Blessed and supported by the adroit professional, our company has emerged as one of the eminent manufacturers and suppliers of Glass Bead. As per the needs and requirements of the clients, we are offering these industrial abrasives in various packing sizes. These Glass Bead are used in blasting cabinets for honing, polishing, peening, blending, finishing, removing light burrs and cleaning most light foreign matter. We are offering these abrasives at cost effective price in the market.
Glass beads are made using lead-free, soda lime-type glass, comprising no free silica which is then formed into preformed ball figures. Chemically inactive and ecologically friendly, glass beads are an adequate technique of metal cleaning or superficial finishing when appropriately measured. Glass beads are extremely utilized in the influence treatment of exterior. Their spherical figure and chemical nature bestow them with a diversity of features that no other surface treatment mediator has, combined.
They are formed like faultless spheres with an even, shining surface. They are obtainable in succeeding granulometric series of 1 to 1000 microns. Throughout projection, each microbead works like a minor hammer on the exterior of the part to be treated.
Size:
TECHNICAL SPECIFICATION | |||
FOR GLASS BEADS MICROBEADS | |||
PARTICULER SIZE RANGE | Standards | ||
| measured on ASTM E11-70 sieve - Passing | ||
| |||
425-850 | 1000 | µm | 99 to 100% |
850 | µm | 90 to 100% | |
425 | µm | 0 to 10% | |
| |||
300-400 | 500 | µm | 99 to 100% |
425 | µm | 90 to 100% | |
250 | µm | 0 to 10% | |
| |||
200-300 | 355 | µm | 99 to 100% |
300 | µm | 90 to 100% | |
180 | µm | 0 to 10% | |
| |||
150-250 | 300 | µm | 99 to 100% |
250 | µm | 90 to 100% | |
150 | µm | 0 to 10% | |
| |||
100-200 | 250 | µm | 99 to 100% |
212 | µm | 90 to 100% | |
106 | µm | 0 to 10% | |
| |||
90-150 | 180 | µm | 99 to 100% |
150 | µm | 90 to 100% | |
75 | µm | 0 to 10% | |
| |||
70-110 | 125 | µm | 99 to 100% |
106 | µm | 90 to 100% | |
53 | µm | 0 to 10% | |
| |||
40-70 | 106 | µm | 99 to 100% |
90 | µm | 90 to 100% | |
45 | µm | 0 to 10% | |
| |||
0-50 | 90 | µm | 99 to 100% |
63 | µm | 90 to 100% | |
45 | µm | 0 to 10% |
Technical Specification :
Symbol | Name | Percentage |
SiO2 (total) | (Silicon Dioxide - Total) | 72% |
Na2O | (Sodium Oxide) | 13% |
CaO | (Calcium Oxide) | 5% |
MgO | (Magnesium Oxide) | 4% |
K2O | (Potassium Oxide) | 3% |
Al2O3 | (Aluminum Oxide) | 1% |
Characteristics :
Colour: | Colourless and transparent, with no visible bubbles or impurities |
Bulk Density: | 1.5 - 1.6 g/cm3 |
Specific Gravity: | 2.5 |
Grain Shape: | Round/Spherical |
Solubility: | Insoluble |
Hardness: | 5.5 - 6.0 Mohs |
Application:
Glass Bead is an adaptable air-blasting media utilized in a diversity of different applications:
Surface finishing
Glass Bead blasting can be utilized on an extensive range of substances with glass, plastic, metal, and rubber. The littler the glass spheres, the evener the surface; greater spheres produce an extra textured finish. To defend specific areas or in detail etching resolves, areas can be effortlessly masked with tape
Features:
It offers a controlled and continuous roughness
It masks external defects
It attains a clean, smooth and lustrous surface. Permit anti-reflection treatment
It permits decorative surfaces (cutlery, jewelry...)
Cleaning
Glass Bead blasting eliminates/cleans foreign materials from the external without a dimensional alteration to the surface. A wide range of bead sizes is available. For example: removing paint, degreasing, light corrosion, and nearly any other surface pollutants. Glass beads may also be utilized to make surfaces for paint adhesion, gasket sealing, or lubrication retention.
Features:
It does not source harm to the product and its measurement
Send Online Query
It offers a smooth and economic cleaning
It fits frequent cleaning
It is utilized on welding surface
It eliminates surface corrosion, flame stains...
Deburring
Glass Bead blasting removes burrs, feathered edges, and alternating from portions in an accuracy process. Corners and edges must be deburred with accuracy to assemble and operate correctly. Glass bead blasting promises that no base metal from the exterior is removed. Gentle and finished areas may be easily masked for protection
Features:
Remove burrs
Clean, with high precision, pieces without damaging cutting edges
Take away any surface property
Perform all processing in one time
Easily reproducible, even on products with high dimensional tolerance
Shot peening
Peening with Glass Bead is a less-cost form of generating an unchanging surface coating of crushed stress in alloy materials. Peening turns to combat stress cracks and rust, resultant in growing the life of metal portions. The high degree of chubbiness of our Glass Bead media increases the performance of stress confrontation processes.
Features:
Decrease crack spread and rust of pieces while growing life cycle
Generate a surface layer of compression, measured breadth, without detrimental the surface
Do not pollute parts cheers to the chemical neutrality mainly appropriate for fragments in stainless steel, titanium, superior alloys...
Get the desired level of shot peening without altering the dimension or form of pieces.
![]() |
